Ip67 waterproof wire 3 To 1 Y branch solar PV cable connector For Solar System

RATED VOLTAGE: 1000V/1500V
PRODUCT NAME: Solar Connector
CONTACT RESISTANCE: <5mΩ
CONTACT MATERIAL: Copper,Tin Plated
CONNECTOR TYPE: Male & Female Solar Connector
TEST VOLTAGE: 8kV(50Hz,1 Min)
PINS: 1pin
WATERPROOF PROTECTION: IP68

Category:

Description

Simple on-site processing
Mating safety provided by keyed housings
Mutiple plugging and unplugging cycles
Accomodates PV cable with deferent insulation diamaters
High Voltage and Current carrying capacity
TUV and CE approved

Specification

Product Name CY4 1 Pair of Y Branch Solar Panel Cable Connectors cable
Brand Name Hochiry Model Number MCY102
Length 30cm Application Power Station
Connector MC4 male Wire AWG10#~14#
MC4 female PVC
Shielding: braid Color black
MOQ 100 pcs Customization OEM/ODM
Packaging Polybag or oem packing Weight 100g
Certification RoHs Warranty 1 year
Specification • Insulation Material: PPO
• Rated Current: 20A(4mm²)
• Rated Voltage: DC1000V
• Contact Resistance: ≤5mΩ
• Insulation Resistance: >500mΩ
• Operating Temperature range: -40℃ until+90℃
• Degree of Protection: IP67
• Flame Class: UL94-V0
• Safety Degree: Ⅱ
• Suitable Single Core Cable Section: 1.5mm²– 6mm² ( include AWG14, AWG13,AWG12, AWG11,AWG10 )
